34
NCJ6FA-V NCJ6FA-H-0 NCJ6FA-V-0
NCJ6FA-V NCJ6FA-H
innovative solutions I superior quality
X L R C h a s s i s C o n n e c t o r s A c c e s s o r i e s
• Combined 3 pole XLR receptacle and 1/4“ phone jack for bal-
anced mic and line or instrument inputs in one XLR housing
• Dramatic space saving – 15% over the predecessor Combo
• Two connectors in one housing – substantial cost, material
and labour saving
• Horizontal and vertical PCB mount available
• 3 pole female XLR combined with stereo TRS jack
• Very low conductor capacitance – ideal for digital audio
• Front panel cut-out compatible with Neutrik XLR A Series
• Branded with unique hologram – guarantees genuine and
authentic Neutrik product
C o m b o A S e r i e s
NCJ6FA-V NCJ6FA-H
Horizontal PCB
mount Vertical PCB mount Hologram
