23 www.neutrik.com
Shell Zinc diecast (ZnAI4Cu1)   -    
Stainless steel - - - - - - -
Shell plating gal Ni or black Cr  gal Ni - velour Cr   
Insert Polyamide PA 6.6 30% GR    PPS 40% GR   
Contacts - female 3 pole: Bronze (CuSn8)       
- female 4 – 7 pole & male: Brass (CuZn39Pb3)      - -
Contact surface Silver gal 2 µm Ag  - - -   -
Gold gal 0.2 µm Au hard alloy over 2 µm Ni      - 
Latch lock St3K32 (latch) / Ck 67 (spring) - - - - - - -
Zinc diecast (ZnAI4Cu1) / CK67 (Spring)       
Strain-relief clamp POM       
Bushing PA / PU       
Circumferential ground spring Bronze (CuSn6), Ni plated -  - - - - -
Crimp ferrule Brass (CuZn39Pb3), Ni plated - - - - - - -
Coding ring Polyamide PA 6 15% GR - - - - - - -
Sealing jacket EPDM - -  - - - -
Securing ring Brass (CuZn39Pb3) - - - - - - -
Lifetime > 1`000 cycles       
Insertion / withdrawal force ≤ 20 N       
Cable O.D. range 3.5 - 8.0 mm  2)  6.0 - 8.0 mm    
Max. wire size 3 pole: 2.5 mm 2
/ AWG 14
 AWG 20    - 
4 pole: 1.5 mm 2
/ AWG 16
 - - -  - -
5, 6, 7 pole: 1.0 mm 2
/ AWG 18
 - - -  - -
Crimp tool: 6.5 mm Hex die (size "E" acc. to IEC 60352-2) - - - - -  -
Crimp XX: 0.22 - 0.34 mm 2
/ AWG 24 - 22 - - - - - 
Number of contacts 3 - 7 1) 3 3 3 3 - 7 3 3
Contact resistance ≤ 3 m Ω       
Insulation resistance - initial: > 10 G Ω       
- after damp heat test: > 1 G Ω       
Dielectric strength 1.5 kV dc       
Cable shield-shell connection choosable  -     
determined - capacitive - - - - -
Shielding effectiveness > 55 dB @ 1.3 GHz -  - - - - -
Lossy ferrite bead on PIN 1 -  - - - - -
Rated current per contact @ 35°C
3 pole: 16 A  5 A    1 A 
4 pole: 10 A  - - -  - -
5, 6 pole: 7.5 A  - - -  - -
7 pole: 5 A  - - -  - -
Capacitance between contacts
3 pole: ≤ 4 pF       
4, 5, 6 pole: ≤ 7 pF  - - -  - -
7 pole: ≤ 9 pF  - - -  - -
Rated Voltage 50 V ac       
Operating temperature -30 °C to +80 °C       
Flammability UL 94 HB    V-0   
Protection class IP 40   IP 67    
Solderability complies with IEC 68-2-20       
Manufacturing Standard IEC 61076-2-103       
Specification XX & EMC XX-HD XX-HE RX XX Crimp convert-
XX-14 &
Series Series Series Series Series CON
CRYSTAL Series
E l e c t r i c a l
M e c h a n i c a l
M a t e r i a l
E n v i r o n m e n t a l
1) : XX-14, CRYSTAL: 3 pole 2) : XX-14: Cable O.D. 8.0 – 10.0 mm
X L R C a b l e C o n n e c t o r s T e c h n i c a l D a t a
