TDU Trolley
Item
Part Number
Description
Quantity
1
2151001
Trolley side plate
2
2
2143001
Drive wheel
2
3
558913
Idler wheel
2
4
558915
Wheel axle
4
5
2229922
Transformer 460/575 Volt
1
5
2229923
Transformer 230 Volt
1
5
Transformer 208 Volt
1
6
2221067
Counterweight set
1
7
833704
Wheel bearing
8
8
300077
Retaining ring
4
9
830860
Retaining ring
4
10
-
Cross head bar
2
13
832112
Washer 4 mm
As required
13
832113
Washer 2 mm
As required
14
831540
Nut
4
15
831576
PAL locking nut
4
16
558941
Coupling plate
2
17
558944
Spacer tube
2
18
400078
Retaining ring
4
19
558947
Suspension axle
1
20
832110
Washer
1
21
831523
Nut
1
22
831575
PAL locking nut
1
25
2220000
Gearmotor assembly
1
26
830915
Screw M8 x 35
4
27
830210
Screw M8 x 30
6
28
2222003
Coupling part
1
34
2142004
Adapter
1
36
558993
Rubber bumper
4
37a
602910
Tow arm 170mm
1
37a
602911
Tow arm 400mm
1
37b
558996
Tow arm support 125mm
1
37b
558997
Tow arm support 235mm
1
37b
558998
Tow arm support 335mm
1
37b
558999
Tow arm support 435mm
1
37c
7215453J
Screw M6 x 16
2
38
Limit switch
1
