13
2-2-7. Capacitance (F)
A) Rotate function switch to “
“.
B) Insert the black test lead to “COM” terminal and red test
lead to “ “ terminal or insert the test socket.
C) Connect the tested capacity by the test leads to “COM”,
“ “ input terminal or insert the test socket hole Cx - / +,
the screen will show capacitance parameter. (The relative
value measurement could be conducted by pressing “REL”
button.)
Caution:
1. Fully discharge the tested capacitor in case it damages the
meter.
2. When measuring in-line capacitor, the power should be turned
off and all capacitors should be discharged completely.
3. It takes about 30 seconds to input stable reading at 100uF
Range.
Range Accuracy Resolution
4nF ±(5.0%+9d)
1 pF
40nF 10pF
400nF 100pF
4μF 1nF
40μF ±(3.5%+8d)
10nF
100μF ±(5.0%+8d) 100nF
• Overload Protection: 250V DC or AC Peak Value.
