-19-
5. ACCESSORIES
5.1 SUPPLIED WITH THE MUL TIMETER
Test leads Electric Rating 1000V, 10A MASTECH HYTL- 60
Battery 9V NEDA 1604 or 6F22
Operating Manual HYS004240
Holster HYHT-60
5.2 How to use the holster
The holster is used to protect the meter and to make the measurement more comfortable.
It comes with two stands installed together. The figure shows how to use the holster to:
a.
b.
c.
d.
Support the meter with a standard angle.
Support the meter with a small angle using the little stand
Hang the meter on the wall using the little stand. Take the little stand off from the back
side of the large stand and insert it into holes located upper on the holster.
Hold test leads.
-20-
6. BATTERY & FUSE REPLACEMENT
If the sign” ”appears on the LCD display, it indicates that battery should be replaced.
Remove screws on the back cover and open the case. Replace the exhausted battery with a
new one.
Fuse rarely need replacement and blow almost always as a result of the operator’s error.
Open the case as mentioned above, and then take the PCB out from the front cover. Replace
the blown fuse with same ratings.
WARNING
Before attempting to open the case, be sure that test leads have been disconnected from
measurement circuits to avoid electric shock hazard.
For protection against fire, replace fuse only with specified ratings:
F1: F 2A/250V F2: F 10A/250V
