4.4 DC CURRENT
Range Resolution Accuracy Burden Voltage
20 μA
200 μA
2mA
20mA
200mA
2A
10A
0.01 μA
0.1 μA
1 μA
10 μA
0.1mA
2A
10mA
±2.0% of rdg ± 5 digits
±0.8% of rdg ± 1 digit
±0.8% of rdg ± 1 digit
±0.8% of rdg ± 1 digit
±1.5% of rdg ± 1 digit
±1.5% of rdg ± 1 digit
±2.0% of rdg ± 5 digit 10mV/ μA
1.0mV/ μA
100mV/mA
11mV/mA
2.0mV/mA
0.4V/A
0.03V/A
Overload Protection: F 2A fuse for 20
μA to 2A ranges, F 10A fuse for 10A range.
-16-
4.5 AC CURRENT
Range Resolution Accuracy Burden Voltage
200
μA
2mA
20mA
200mA
2A
10A
0.1
μA
1
μA
10
μA
0.1mA
1mA
10mA
±1.8% of rdg ± 3 digits
±1.0% of rdg ± 3 digits
±1.0% of rdg ± 3 digits
±1.8% of rdg ± 3 digits
±1.8% of rdg ± 3 digits
±3.0% of rdg ± 7 digits
1.0mV/
μA
100mV/mA
11mV/mA
2.0mV/mA
0.4V/A
0.03V/A
Overload Protection: F 2A fuse for 20
μA to 2A ranges, F 10A fuse for 10A range.
Frequency Range: 40Hz to 400Hz
Response:Average, Calibrated in rms of sine wave
-17-
4.6 RESISTANCE
Range Resolution Accuracy
200 Ω
2K Ω
20K Ω
200K Ω
2M Ω
20M Ω
200M Ω
0.1 Ω
1 Ω
10 Ω
100 Ω
1K Ω
10K Ω
100K Ω
±0.8% of rdg ± 3 digits
±0.8% of rdg ± 1 digit
±0.8% of rdg ± 1 digit
±0.8% of rdg ± 1 digit
±0.8% of rdg ± 1 digit
±1.0% of rdg ± 1 digit
±5.0% of (rdg –10 digits)± 10digits
Note: On 200M Ω range, if short input, display will read 1 MΩ, this 1MΩ should be
subtracted from measurement results.
-18-
4.7 DIODE
Range Description Test Condition
Shows the approximate
forward voltage drop
Forward Current 1mA
Vce 3.2V
4.8 CONTINUITY
Range Description
Built-in buzzer will sound, if the resistance under test is less
than about 70 Ω
