Outer ring 2x115 2x72
Inner ring 70 46
Electrical connection
• Ground the appliance according to safety precautions.
• Make sure that the rated voltage and type of power on the rating plate agree with the
voltage and the power of the local power supply.
• This appliance is supplied with a mains cable.
• Any electrical component must be installed or replaced by the Service Force Centre tech-
nician or qualified service personnel.
• Always use a correctly installed shockproof socket.
• Make sure that there is an access to the mains plug after installation.
• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.
• The appliance must not be connected with an extansion cable, an adapter or a multiple
connection (risk of fire). Check that the ground connection is in conformity with the
standard and regulations force.
• The power cable must be placed in such a way that it does not touch any hot part.
• Connect the appliance to the mains with a device that lets to disconnect the appliance
from the mains at all poles with a contact opening width of minimum 3 mm, eg. auto-
matic line protecting cut-out, earth leakage trips or fuse.
• None of a parts of the connection cable can not get a temperature 90°C.
Replacement of the connection cable
In order to replace the connection cable speak your local Service Force Centre!
To replace the connection cable use only H05BB-F Tmax 90°C (or higher) type. Make sure
that the cable section is applicable to the power and the working temperature. The yellow/
green earth wire must be approximately 2 cm longer than all phase wires.
Assembly
min.
450mm
min.
650mm
Installation 35
