4. Assemble the parts, follow the same procedure backwards.
5. Replace the rating label (it is near the gas supply pipe) with the one for the new type
of gas supply. You can find this label in the package of the injectors supplied with the
appliance.
Adjustment of minimum level
To adjust the minimum level of the burners:
1.
Light the burner.
2. Turn the knob on the minimum position.
3. Remove the knob.
4. With a thin screwdriver, adjust the by-pass screw position.
1
1 The by-pass screw
– If you change from natural gas G20 20 mbar to liquid gas, fully tighten the adjust-
ment screw in.
– If you change from liquid gas to natural gas G20 20 mbar, undo the by-pass screw
approximately 1/4 of a turn.
WARNING!
Make sure the flame does not go out when you quickly turn the knob from the maximum
position to the minimum position.
BURNER NATURAL GAS
G20/20 mbar
LPG
G30/30 mbar
Injectors Injectors
34 Installation
