IMPORTANT! Read entire instruction sheet before you start installation and assembly.
Models:
SPK 811, SPK 811W
MAXIMUM LOAD CAPACITY:
20 lb (9 kg) each mount.
For customer service, call 1-800-729-0307 or 708-865-8870.
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
Description
mounting base
extension
cap
ball
M4 x .7 x 10 mm phillips screw
M5 x .8 x 8 mm phillips screw
M6 x 1 x 10 mm phillips screw
1/4-20 x 1/2 phillips screw
10-32 x .313 phillips screw
#10 x 3/4 phillips wood screw
1/4-20 serrated locknut
#10 flat washer
1/4-20 keyhole adapter
1/4-20 to M5 reducer
1/4-20 to M4 reducer
1/4-20 coupling
mounting plate
toggler
#10-24 x 2" phillips screw
plastic #10 screw plug
concrete anchor
#10 x 1 1/2" wood screw
M4 KEPS hex nut
M4 serrated washer
M4 x 16 mm socket pin screw
Qty.
1
1
1
1
4
4
4
4
2
4
2
2
1
1
1
1
1
2
2
2
2
2
2
2
2
Parts List
A B C
M N O
L
P
R
U
E F G H
I J
S V
Q
T
Tools Required: Drill,
screwdriver, two 7/16"
open end wrenches,
channel locks, hammer,
pencil, tape measure, level.
K
Assembly Instructions - Universal Speaker Mounts
D
If you are missing a fastener, please contact our customer service department before returning the speaker mounts to store from which they
were purchased.
SPK 811
590-1144
590-1145
590-1146
590-1147
504-9012
570-0005
520-9401
510-9108
520-1173
500-9006
530-1021
540-9400
580-1026
580-1027
580-1028
580-1029
087-1037
560-9717
520-2078
590-1158
590-0097
510-9163
530-1041
540-1033
510-1087
SPK 811W
590-2144
590-2145
590-2146
590-2147
520-2027
520-9530
520-9524
520-9511
520-2173
500-2014
530-2021
540-9442
580-2026
580-2027
580-2028
580-2029
087-2037
560-9717
520-2078
590-2158
590-0097
500-2002
530-2041
540-2033
510-2087
Y X W
