Removal of freezing baskets and glass shelves from the freezer
Some of the freezing baskets have a limit stop to
prevent their accidental removal or falling out. At
the time of its removal from the freezer, pull the
basket towards yourself and, upon reaching the
end point, remove the basket by tilting its front
upwards.
At the time of putting it back, slightly lift the
front of the basket to insert it into the freezer.
Once you are over the end points, push the basket
back in their position.
The appliance is equipped with shelf stops to se-
cure the shelves.
The shelves must be lifted up (1) on each side and
than pulled outwards (2).
The glass shelves equipped with expander rollers
are secured with locking pins.
To remove them proceed as follow:
1.
Use a screwdriver to loosen the locking pin
on each side on the expander roller.
2. Then pull out both locking pin (1).
3. Then pull the glass shelf outwards (2).
HELPFUL HINTS AND TIPS
Normal Operating Sounds
• You may hear a faint gurgling and a bubbling sound when the refrigerant is pumped
through the coils or tubing. This is correct.
• When the compressor is on, the refrigerant is being pumped around and you will hear a
whirring sound and a pulsating noise from the compressor. This is correct.
2
1
1 2
1
2
1
1
1
30 Helpful hints and tips
