3.4 Back View Description
1KVA Tower Case
1. DB 9 (RS-232) Interface Port 6. Fan
2. SNMP Intelligent Slot (Option) 7. External Battery Socket
3. Fax / Modem (Surge
Protection)
8. Breaker
4. Remote Control
(Detachable LCD Panel)
9. Input Socket
5. Output Socket (NEMA or IEC)
11
2KVA / 3KVA Tower Case
1. DB 9 (RS-232) Interface Port 7. External Battery Socket
2. SNMP Intelligent Slot (Option) 8. Fan
3. Fax / Modem (Surge Protection) 9 Breaker
4. Remote Control
(Detachable LCD Panel)
10. Input Terminal
5. Output Socket (NEMA or IEC)
6. Output Terminal
