3.7 AC output
3.8 Battery and Charger
Internal battery package Panasonic LC-RW1245W CSB HR1234WF2
Dimensions
94*151*64.5/pc 94*151*65/pc
Strings 2 x 15 2 x 15
Charger Input Protection 8 A fuse
Rated Charge Voltage ±202V Default for Integrated battery
Initial Charging Current 4.5A
Battery Leakage < 3.5mA
Battery protection
100A Fuse For internal battery
Stored energy time Up to 580s At Rated linear Load , 25℃
Restored energy time <5Hours Up to 90% charge
30A Fuse*3 For PCBA level
Max discharging current 62A Ubat=288VDC, Full RCD load
Frequency 50/60HZ
Active power 16KW
Number of phases 3-phases + N
VFI 20000TP 3/3 BE/BI
Overload
capability
(Mains
available)
Voltage (L-N) 220/230/240 VAC
110%
10 minutes minimum,
then transfer to bypass and alarm
125%
Load>150%
1 minutes minimum,
then transfer to bypass and alarm
0.5 seconds minimum,
then transfer to bypass and alarm
10 minutes minimum,
then transfer to bypass and alarm
1 minutes minimum,
then transfer to bypass and alarm
0.5 seconds minimum,
then transfer to bypass and alarm
110%
125%
Load>150%
Overload
capability
(battery
available)
