SAFETY

ype 1

FOLD / UNFOLD

SEATBACK POSITIONING

The seat has a multiple position recline that is

controlled by a strap and buckle assembly behind

the seat. (Fig. 19) To recline the seat, loosen the

strap through the buckle and adjust to the required

recline position. (Fig. 20) To place the seat back

in a more upright position, press upward on the

seat back with one hand while pulling the strap

through the buckle with the other. The strap will

lock automatically.

The upright position should be used only for a

child that is at least 6 months old. Always re-

adjust the safety harness, including the shoulder

belts, when repositioning the seatback.

JOGGING WITH YOUR STROLLER

When you are jogging with your child, use the

following safety features:

• LOCK THE FRONT SWIVEL WHEEL IN

STRAIGHT POSITION (Type 2 only)

• SAFETY WRIST STRAP: Always connect

the safety strap to either wrist when jogging.

This strap will keep the stroller from rolling

away in the event that you trip while running.

(Fig. 21) The safety strap must remain

connected to the rear lower frame cross

member at all times. This location is intended

to prevent the stroller being tipped backward

in the event that you do fall to the ground.

The safety strap includes a Velcro attachment

for storage, on the left side of the stroller,

when not in use. (Fig. 22)

• CALIPER BRAKE SYSTEM: Squeeze

the brake handle to slow the stroller.

(Fig. 16)

NEVER

use the hand brake as a

parking brake. This feature is only available

on Type 1 stroller.

TIRES

Tires are shipped un-inflated. The tires should

be inflated on a regular basis to between 20 to 25

pounds of air pressure. Always use a bicycle style

hand air pump to inflate the tires.

Handle Button Release

WARNING:

Care must be

taken when folding and unfolding

the stroller to prevent finger

entrapment.

TO FOLD STROLLER

Close the canopy as described in the canopy

section. Recline seat by releasing buckle as

described in seatback positioning section.
The stroller is folded by simultaneously

depressing the safety lock on the right side and

fold buttons located on the central joints. (Fig. 23)

When the fold latches are released, the handle will

begin to fall toward the floor. Release the fold

buttons and press downward on the stroller handle

until the stroller is completely folded. Secure the

stroller in the folded position by hooking the fold

latch, located on the right side of the stroller, over

the rivet that protrudes from the frame. (Fig. 24)

WARNING:

Care must be

taken when folding and unfolding

the stroller to prevent finger

entrapment.

TO UNFOLD STROLLER

Stand the stroller on the ground with all three

wheels touching the ground. Release the folding

latch, which is located on the right side. (Fig. 25)
Lift up on the stroller handle with both hands until

the stroller frame is erect and locked in the open

position. (Fig. 26) The stroller has spring-loaded

latches on both sides of the frame. Test that both

latches are fully engaged prior to placing your

child in the stroller.

Fig. 21

Fig. 22

Fig. 20

Fig. 19

Fig. 23

Fig. 24

Fig. 25

Fig. 26
