Page 6: Type 1, 2t ype 1

Fig. 18a

Fig. 18b

Shoulder Strap

Squeeze

Adjust for a snug fit

Crotch Strap

Waist Strap

SAFETY

ype 1

Before placing your children in the stroller,

please follow the instructions below.

WARNING:

Always

check with your pediatrician for a

recommended starting age / weight

for your baby in an all terrain stroller.

WARNING:

Always set

brakes when the stroller is not being

pushed so that the stroller will not

roll away. NEVER leave stroller

unattended on a hill or incline as

the stroller may slide down the hill.

BRAKES

To engage brakes, apply light downward pressure

to the brake lever located on each rear wheel. The

stroller may require slight forward or rearward

movement in order to line up the teeth on the

brake with each wheel brake cluster. (Fig. 14)

Check that the stroller will not move and that both

brakes are properly applied. To release, gently lift

up on the brake lever.
Your stroller may come equipped with a caliper

brake system. (Fig. 15) The front wheel bicycle

style caliper brake system that is designed to assist

you in slowing the stroller on a hill or in the event

of an emergency. Squeeze the brake handle to

slow the stroller. (Fig. 16) The hand brake is not

to be used as a parking brake.

WARNING:

Always lock

the front swivel wheel in STRAIGHT

position before placing or removing

your children from the jogger.

The type 2 swivel jogger come equipped with a

front wheel locking device. Fig. 17a is a remote

release lever located under the right side handle.

Pull to disengage the wheel and push to engage

SAFETY

the locking device located under the footrest.

Fig. 17b front wheel lock works in a horizontal

motion from left to right, locking and unlocking

the wheel. Fig. 17c front wheel lock works in a

vertical motion from top to bottom, locking and

unlocking the wheel.

WARNING:

Avoid serious

injury from falling or sliding out.

Always use the safety harness.

STRANGULATION

HAZARD:

Child can

strangle in loose straps. Never leave

child in seat when straps are loose

or undone.

TO SECURE THE CHILD

The shoulder straps of the 5-point harness have

2 attachment positions. Select the position that

places the shoulder strap level with, or below the

top of the child's shoulder.

• Carefully place the child in the stroller seat

and bring the safety harness around the

child's waist and over the shoulders. Place the

crotch strap between the child's legs. Insert

the male end of each shoulder/waist belt into

the buckle on the crotch strap. Tighten the

harness to be snug around the child's waist

and over the child's shoulders Please see

figure 18a.

• To release, apply pressure to both sides of

each male clip until the clip is released. See

figure 18b. This process requires a moderate

amount of effort so as to prevent an accidental

release by your child.

Fig. 14

Fig. 15

Fig. 16

Type 1 only

Type 2 only

Fig. 17a

Fig. 17b

Fig. 17c

Unlock Lock

Lock

Unlock
