Dual Electronics XDVD3101 - Manual (Page 10)

9
Volume/Power On/Off
Opening/Angling the Screen
Volume Memory
Mute
Mode
3.5mm A/V Input
Menu
Momentarily press the volume knob to turn the unit on. Hold for 2 seconds
to turn the unit off. Turn the volume knob to adjust the volume level lower or
higher (0-40).
Press OPEN/ANGLE to open or close the display screen. When the screen is
open, press and hold OPEN/ANGLE to change the screen angle.
If the volume level is <21 when the unit is turned off, it will be retained in
memory the next time the unit is turned on. If the volume level is >20 when the
unit is turned off, the volume level will automatically default to 20 the next time
the unit is turned on.
Momentarily press the volume knob (MUTE) to silence the audio; will appear
on the OSD (On Screen Display). Momentarily press the volume knob (MUTE)
again to cancel. Turning the volume knob while the volume is muted will also
cancel the mute function.
Press MODE to step through all available input modes: Tuner, Disc (which
includes DVD and CD playback), SD, USB, operation of iPod, AV1, AV2 and
Camera. Modes of operation are indicated on the OSD On Screen Display.
Optional iPod device, USB flash drive and SD card must be connected/inserted
to appear in the mode selection string.
When the screen is open, icons for non-selected modes are displayed across
the top center region of the display. Directly access a different mode by
touching the corresponding icon. Modes of operation can also be accessed from
the Main Menu screen (see below).
Connect external audio/video devices to this 3.5mm auxiliary A/V input.
Press MENU to view/select any operational mode (Tuner, Disc, USB, iPod, SD,
AV1, AV2 or Camera), to enter the Setup menu or to put the unit in Standby mode.
The Main Menu screen can also be accessed from all other modes by pressing
the key area in the top left corner of the touchscreen.
General Operation
XDVD3101 OPERATION
