weber Drehspie? Genesis - Manual (Page 3)

3
(1)
Assembly
5. set the Rotisserie shaft on Rotisserie
support block
place the handle(1) end of rotisserie on the
support notch.
4. Insert the Rotisserie shaft in the
motor
Insert the pointed end of the rotisserie shaft
into the motor.
3. Put the spit Forks on the Rotisserie
shaft
slide the forks onto the shaft so that the
tines are facing each other. screw in the
thumb screws to hold the forks in place.
2. Attach the motor
slide the motor onto the stainless steel
motor bracket.
1. Install the motor bracket
attach the stainless steel motor bracket to
the left-hand side of the cooking box, using
the 1/4-20 fasteners and the 1/4-20
Keps nuts.
