MAX1742/MAX1842

1A/2.7A, 1MHz, Step-Down Regulators with

Synchronous Rectification and Internal Switches

________________________________________________________________ Maxim Integrated Products

1

19-1760; Rev 1; 2/02

General Description

The MAX1742/MAX1842 constant-off-time, pulse-width-
modulated (PWM) step-down DC-DC converters are ideal
for use in 5V and 3.3V to low-voltage conversion neces-
sary in notebook and subnotebook computers. These
devices feature internal synchronous rectification for high
efficiency and reduced component count. They require
no external Schottky diode. The internal 90m

Ω PMOS

power switch and 70m

Ω NMOS synchronous-rectifier

switch easily deliver continuous load currents up to 1A.
The MAX1742/MAX1842 produce a preset 2.5V, 1.8V, or
1.5V output voltage or an adjustable output from 1.1V to
V

IN

. They achieve efficiencies as high as 95%.

The MAX1742/MAX1842 use a unique current-mode,
constant-off-time, PWM control scheme, which includes
Idle Mode™ to maintain high efficiency during light-load
operation. The programmable constant-off-time architec-
ture sets switching frequencies up to 1MHz, allowing the
user to optimize performance trade-offs between effi-
ciency, output switching noise, component size, and
cost. Both devices are designed for continuous output
currents up to 1A. The MAX1742 uses a peak current
limit of 1.3A (min) and is suitable for applications requir-
ing small external component size and high efficiency.
The MAX1842 has a higher current limit of 3.1A (min)
and is intended for applications requiring an occasional
burst of output current up to 2.7A. Both devices also fea-
ture an adjustable soft-start to limit surge currents during
startup, a 100% duty cycle mode for low-dropout opera-
tion, and a low-power shutdown mode that disconnects
the input from the output and reduces supply current
below 1µA. The MAX1742/MAX1842 are available in 16-
pin QSOP packages.

For similar devices that provide continuous output cur-
rents up to 2A and 3A, refer to the MAX1644 and
MAX1623 data sheets.

Applications

5V or 3.3V to Low-Voltage Conversion

CPU I/O Ring

Chipset Supplies

Notebook and Subnotebook Computers

Features

±1% Output Accuracy
95% Efficiency
Internal PMOS and NMOS Switches

90m

On-Resistance at V

IN

= 4.5V

110m

On-Resistance at V

IN

= 3V

Output Voltage

2.5V, 1.8V, or 1.5V Pin Selectable
1.1V to V

IN

Adjustable

3V to 5.5V Input Voltage Range
600µA (max) Operating Supply Current
<1µA Shutdown Supply Current
Programmable Constant-Off-Time Operation
1MHz (max) Switching Frequency
Idle-Mode Operation at Light Loads
Thermal Shutdown
Adjustable Soft-Start Inrush Current Limiting
100% Duty Cycle During Low-Dropout Operation
Output Short-Circuit Protection
16-Pin QSOP Package

PART

MAX1742EEE

-40°C to +85°C

TEMP RANGE

PIN-PACKAGE

16 QSOP

Ordering Information

Idle Mode is a trademark of Maxim Integrated Products.

Typical Configuration

TOFF

COMP

V

CC

FBSEL

SHDN

IN

PGND

GND

REF

SS

LX

FB

MAX1742
MAX1842

OUTPUT
1.1V TO
V

IN

INPUT

3V TO

5.5V

0.01

µF

1

µF

2.2

µF

470pF

10

MAX1842EEE

-40°C to +85°C

16 QSOP

Pin Configuration appears at end of data sheet.

For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.

EVALUATION KIT

AVAILABLE
