Specifications for fax
Group 3, class 1& 2
Specifications for data
Specifications for SMS via GSM /
GPRS
Point-to-point MO and MT
SMS cell broadcast
Text and PDU mode
General features
Specifications for voice
Drivers
MUX Driver
Compatibility
AT cellular command interface
M10
Quad Band GSM/GPRS Module
29mm
29mm 3.6mm
Quad-Band 850/ 900/ 1800/ 1900 MHz
GPRS multi-slot class 12/10/8
GPRS mobile station class B
Compliant to GSM
phase 2/2+ Class 4
(2W @850/ 900 MHz)
Class 1
(1W @1800/1900MHz)
Supply voltage range 3.4~4.5 V 4.0V nominal
Low power
consumption
1.1mA @ DRX=5
0.7mA @ DRX=9
Operation
temperature
-45 °C to +85 °C
Dimensions 29mm × 29mm × 3.6mm
Weight Approx 6g
Control via AT commands (GSM 07.07 ,07.05
and other enhanced AT Commands)
SIM application toolkit
Speech codec modes Half rate (HR)
Full rate (FR)
Enhanced Full rate (EFR)
AMR half rate
AMR full rate
Echo arithmetic
Echo cancellation
Echo suppression
Noise Reduction
Hands-free operation
External SIM 3V/ 1.8V
Analog audio interfaces Two channels
RTC backup
Keypad interface
LCD interface
Serial port and debug port
Antenna pad
Charge interface ( Optional)
GPIOs
Interfaces
Contact us
Address
Room 801, Building E, No.1618,
Yishan Road, Shanghai, China
Email
[email protected]
Tel + 86 21 51082965
GPRS class 12 max. 85.6 kbps (uplink
& downlink)
PBCCH support
Coding schemes CS 1, 2, 3, 4
CSD up to 14.4 kbps
USSD
Non transparent mode
Protocols
PPP
TCP/IP
HTTP
FTP
MMS
Approvals
CE
FCC
GCF
PTCRB
