MAX1209
12-Bit, 80Msps, 3.3V IF-Sampling ADC
_______________________________________________________________________________________ 3
ELECTRICAL CHARACTERISTICS (continued)
(V DD = 3.3V, OV DD = 2.0V, GND = 0, REFIN = REFOUT (internal reference), V IN = -0.5dBFS, CLKTYP = high, DCE = high, PD = low,
G/T = low, f CLK = 80MHz (50% duty cycle), T A = -40°C to +85°C, unless otherwise noted. Typical values are at T A = +25°C.) (Note 1)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
f IN = 70MHz at -0.5dBFS 85.1
f IN = 100MHz at -0.5dBFS 86.2 Spurious-Free Dynamic Range SFDR
f IN = 175MHz at -0.5dBFS (Note 6) 74.6 85.5
dBc
f IN = 70MHz at -0.5dBFS -81.2
f IN = 100MHz at -0.5dBFS -82.3 Total Harmonic Distortion THD
f IN = 175MHz at -0.5dBFS -82.7 -73.9
dBc
f IN = 70MHz at -0.5dBFS -86.5
f IN = 100MHz at -0.5dBFS -89.6 Second Harmonic HD2
f IN = 175MHz at -0.5dBFS -89
dBc
f IN = 70MHz at -0.5dBFS -85.1
f IN = 100MHz at -0.5dBFS -86.5 Third Harmonic HD3
f IN = 175MHz at -0.5dBFS -88.6
dBc
f IN1 = 68.5MHz at -7dBFS,
f IN2 = 71.5MHz at -7dBFS
-82.4
Intermodulation Distortion IMD
f IN1 = 172.5MHz at -7dBFS,
f IN2 = 177.5MHz at -7dBFS
-74.2
dBc
f IN1 = 68.5MHz at -7dBFS,
f IN2 = 71.5MHz at -7dBFS
-86.4
Third-Order Intermodulation IM3
f IN1 = 172.5MHz at -7dBFS,
f IN2 = 177.5MHz at -7dBFS
-86.1
dBc
f IN1 = 68.5MHz at -7dBFS,
f IN2 = 71.5MHz at -7dBFS
85.1
Two-Tone Spurious-Free
Dynamic Range
SFDR
TT
f IN1 = 172.5MHz at -7dBFS,
f IN2 = 177.5MHz at -7dBFS
74.2
dBc
Full-Power Bandwidth FPBW Input at -0.5dBFS, -3dB roll-off 700 MHz
Aperture Delay t AD Figure 4 0.9 ns
Aperture Jitter t AJ Figure 4 <0.2 ps RMS
Output Noise n
OUT
INP = INN = COM 0.52 LSB
RMS
Overdrive Recovery Time ±10% beyond full scale 1
Clock
cycles
