MAX522
Dual, 8-Bit, Voltage-Output
Serial DAC in 8-Pin SO Package
2 _______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(V
DD
= +2.7V to +5.5V, REF = V
DD
, T
A
= T
MIN
to T
MAX
, unless otherwise noted. Typical values are at T
A
= +25°C.)
Note 1: The outputs may be shorted to V
DD
or GND if the package power dissipation is not exceeded. Typical short-circuit current to
GND is 50mA.
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V
DD
to GND ................................................................ -0.3V, +6V
Digital Inputs and Outputs to GND............... -0.3V, (V
DD
+ 0.3V)
REF ................................................................-0.3V, (V
DD
+ 0.3V)
OUTA, OUTB (Note 1)............................................................V
DD
Continuous Power Dissipation (T
A
= +70°C)
Plastic DIP (derate 9.09mW/°C above +70°C) ..............727mW
SO (derate 5.88mW/°C above +70°C) ...........................471mW
Operating Temperature Ranges
MAX522C_ A.......................................................0°C to +70°C
MAX522E_ A....................................................-40°C to +85°C
Storage Temperature Range .............................-65°C to +165°C
Lead Temperature (soldering, 10sec) .............................+300°C
(Note 3)
2.7V ≤ V DD
≤ 3.6V, REF = 2.4V
4.5V ≤ V DD
≤ 5.5V, REF = 4.096V
CONDITIONS
M
Ω
2
Reference Input Resistance
(shutdown mode)
k Ω R
REF Reference Input Resistance 8
pF 25 Reference Input Capacitance
GND V DD
%/%
0.01
PSRR Power-Supply Rejection Ratio
Bits 8 N Resolution
µV/°C 100
Zero-Code Temperature
Coefficient
UNITS MIN TYP MAX SYMBOL PARAMETER
Guaranteed monotonic LSB ±1 DNL Differential Nonlinearity
0.015
(Note 2) LSB ±1.5 INL Integral Nonlinearity
(Note 2) LSB ±1 TUE Total Unadjusted Error
Reference Input Voltage Range V
DAC A
µF
0.1
Capacitive Load at OUT_
DAC A
Ω
50
Output Resistance
V 0 REF Output Voltage Range
V (0.7)(V DD ) V
IH Input High Voltage
V (0.3)(V DD ) V
IL Input Low Voltage
V
IN
= 0V or V
DD µA 0.1 ±10 I
IN Input Current
(Notes 4, 5) pF 10 C
IN Input Capacitance
DAC B
DAC B
0.01
500
STATIC PERFORMANCE
REFERENCE INPUTS
DAC OUTPUTS
DIGITAL INPUTS
