MAX975/MAX977
Single/Dual, +3V/+5V Dual-Speed
Comparators with Auto-Standby
8 _______________________________________________________________________________________
____________________________Typical Operating Characteristics (continued)
(V
CC
= 3.0V, T
A
= +25°C, unless otherwise noted.)
PROPAGATION DELAY t PD-
LOW-POWER MODE (V CC = +3V)
t PD-
INPUT
5mV/div
100ns/div
OUTPUT
1V/div
V OS
V CC
V CC /2
GND
MAX975/977 TOC27
PROPAGATION DELAY t PD+
LOW-POWER MODE (V CC = +3V)
t PD+
INPUT
5mV/div
100ns/div
OUTPUT
1V/div
V OS
V CC
V
CC
/2
GND
MAX975/977 TOC28
PROPAGATION DELAY t PD+
LOW-POWER MODE (V CC = +5V)
t PD+
INPUT
5mV/div
100ns/div
OUTPUT
2V/div
V OS
V CC
V CC /2
GND
MAX975/977 TOC29
PROPAGATION DELAY t PD-
LOW-POWER MODE (V CC = +3V)
t PD-
INPUT
5mV/div
100ns/div
OUTPUT
2V/div
V OS
V CC
V CC /2
GND
MAX975/977 TOC30
PROPAGATION DELAY t PD+
HIGH-SPEED MODE (V
CC
= +5V)
t
PD+
INPUT
5mV/div
5ns/div
OUTPUT
2V/div
V OS
V CC
V CC /2
GND
MAX975/977 TOC26
