MAX2108
Direct-Conversion Tuner IC
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
DC ELECTRICAL CHARACTERISTICS
(V
CC
= +4.75V to +5.25V; V
GC
= 1.3V; PS_SEL = 0.5V; IOUT,
IOUT, QOUT, QOUT = terminated with 2.5k
Ω
to GND; no input signal
applied; T
A
= 0°C to +70°C; unless otherwise noted. Typical values are at V
CC
= +5V, T
A
= +25°C.)
AC ELECTRICAL CHARACTERISTICS
(V
CC
= +5V; PS_SEL = 0.5V; P
RFIN
= -20dBm; f
LO
= f
RFIN
+125kHz; GC set via servo loop for V
IOUT
- V
IOUT
= 200mVp-p (differen-
tial); T
A
= +25°C; unless otherwise noted.)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V
CC
to GND ..............................................................-0.3V to +7V
V
CC
to Any Other V
CC
...........................................-0.3V to +0.3V
All Other Pins to GND.................................-0.3V to (V
CC
+ 0.3V)
RFIN to RFIN ..........................................................................±2V
LO to LO ................................................................................±2V
Short-Circuit Current
IOUT, IOUT, QOUT, QOUT to GND .................................10mA
PSOUT, PSOUT to GND...................................................40mA
Short-Circuit Duration IOUT to IOUT, QOUT to QOUT,
PSOUT to PSOUT ............................................................10sec
Continuous Power Dissipation (T
A
= +70°C)
24 QSOP (derate 10mW/°C above T
A
= +70°C) ..........800mW
Operating Temperature Range...............................0°C to +70°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-65°C to +150°C
Lead Temperature (soldering, 10sec) .............................+300°C
0 < V
PS_SEL
< V
CC
1V < V
GC
< 4V
CONDITIONS
V
0.5
V
THL
PS_SEL Logic-Low Threshold
V
2.4
V
THH
mA
105
152
I
CC
Supply Current
PS_SEL Logic-High Threshold
µA
-30
+10
I
PS_SEL
PS_SEL Input Bias Current
µA
-80
+80
I
GC
GC Input Bias Current
UNITS
MIN
TYP
MAX
SYMBOL
PARAMETER
V
2.9
3.35
3.8
V
CM
IOUT, IOUT, QOUT, QOUT
Common-Mode Output Voltage
950MHz < f
RFIN
< 2150MHz, P
LO
= -5dBm,
V
IOUT
- V
IOUT
= 10mVp-p, T
A
= 0°C +70°C
950MHz < f
RFIN
< 2150MHz, P
LO
= -5dBm
1V < V
GC
< 4V, P
LO
= -5dBm
CONDITIONS
dBm
-70
P
RFINMIN
RFIN Minimum Input Power
(Note 2)
dBm
-20
P
RFINMAX
MHz
950
2150
f
RFIN
RFIN Frequency Range (Note 1)
RFIN Maximum Input Power
(Note 2)
dBm
-5
External LO Drive Level (Note 2)
dB
50
Gain-Control Range (Note 2)
UNITS
MIN
TYP
MAX
SYMBOL
PARAMETER
V
GC
= 4V, f
LO
= 1750MHz
dB
10
NF
Noise Figure
dBm
14
IIP
2
dBm
8
IIP
3
RFIN Input Third-Order
Intercept Point (Note 3)
RFIN Input Second-Order
Intercept Point (Note 4)
