MAX1195
Dual, 8-Bit, 40Msps, 3V, Low-Power ADC with
Internal Reference and Parallel Outputs
_______________________________________________________________________________________ 3
ELECTRICAL CHARACTERISTICS (continued)
(V DD = OV DD = 3V, 0.1µF and 2.2µF capacitors from REFP, REFN, and COM to GND; REFOUT connected to REFIN through a 10k Ω
resistor, V IN = 2V P-P (differential with respect to COM), C L = 10pF at digital outputs, f CLK = 40MHz, T A = T MIN to T MAX , unless
otherwise noted. ≥+25°C guaranteed by production test, <+25°C guaranteed by design and characerization. Typical values are at
T A = +25°C.)
PARAMETER SYMBOL CONDITIONS MIN T YP MAX UNITS
f INA or B = 1MHz at -1dB FS 48.6
f INA or B = 7.5MHz at -1dB FS 48.5
f INA or B = 20MHz at -1dB FS 47 48.5
Signal-to-Noise
and Distortion
SINAD
f INA or B = 115.1MHz at -1dB FS 47.8
dB
f INA or B = 1MHz at -1dB FS 73
f INA or B = 7.5MHz at -1dB FS 69
f INA or B = 20MHz at -1dB FS 60 68.7
Spurious-Free
Dynamic Range
SFDR
f INA or B = 115.1MHz at -1dB FS 63
dBc
f
INA or B
= 1MHz at -1dB FS - 75
f INA or B = 7.5MHz at -1dB FS - 73
f INA or B = 20MHz at -1dB FS - 70
Third-Harmonic
Distortion
HD3
f INA or B = 115.1MHz at -1dB FS - 63
dBc
Intermodulation Distortion
(First Five Odd-Order IMDs)
IMD
f IN1(A or B) = 1.997MHz at -7dB FS
f IN2(A or B) = 2.046MHz at -7dB FS
(Note 2)
- 69.5 dBc
Third-Order Intermodulation
Distortion
IM3
f IN1(A or B) = 1.997MHz at -7dB FS
f IN2(A or B) = 2.046 MHz at -7dB FS
(Note 2)
- 71.7 dBc
f
INA or B
= 1MHz at -1dB FS - 70
f INA or B = 7.5MHz at -1dB FS - 69
f INA or B = 20MHz at -1dB FS - 69 -57
Total Harmonic Distortion
(First Four Harmonics)
THD
f INA or B = 115.1MHz at -1dB FS - 62
dBc
Small-Signal Bandwidth Input at -20dB FS, differential inputs 500 MHz
Full-Power Bandwidth FPBW Input at -1dB FS, differential inputs 400 MHz
Gain Flatness
(12MHz Spacing)
f IN1(A or B) = 106 MHz at -1dB FS
f IN2(A or B) = 118 MHz at -1dB FS
(Note 3)
0.05 dB
Aperture Delay t AD (Note 1) 1 ns
Aperture Jitter t
AJ
1dB SNR degradation at Nyquist 2 ps
RMS
Overdrive Recovery Time For 1.5 × full-scale input 2 ns
IN T ER N A L REF ER EN C E ( RE FIN = RE FOU T thr oug h 10k Ω r esi stor ; RE FP , RE FN , and C OM l evel s ar e g ener ated i nter nal l y.)
Reference Output Voltage V REFOUT (Note 4)
2.048
± 3%
V
Positive Reference Output
Voltage
V REFP (Note 5) 2.012 V
Negative Reference Output
Voltage
V REFN (Note 5) 0.988 V
