MAX1208

12-Bit, 80Msps, 3.3V ADC

_______________________________________________________________________________________

3

ELECTRICAL CHARACTERISTICS (continued)

(V

DD

= 3.3V, OV

DD

= 2.0V, GND = 0, REFIN = REFOUT (internal reference), V

IN

= -0.5dBFS, CLKTYP = high, DCE = high, PD = low,

G/T = low, f

CLK

= 80MHz (50% duty cycle), T

A

= -40°C to +85°C, unless otherwise noted. Typical values are at T

A

= +25°C.) (Note 1)

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX

UNITS

fIN = 3MHz at -0.5dBFS

89.3

fIN = 32.5MHz at -0.5dBFS

78.7

88.2

Spurious-Free Dynamic Range

SFDR

fIN = 70MHz at -0.5dBFS

85.1

dBc

fIN = 3MHz at -0.5dBFS

-87.1

fIN = 32.5MHz at -0.5dBFS

-85.0

-77.2

Total Harmonic Distortion

THD

fIN = 70MHz at -0.5dBFS

-81.2

dBc

fIN = 3MHz at -0.5dBFS

-93

fIN = 32.5MHz at -0.5dBFS

-89

Second Harmonic

HD2

fIN = 70MHz at -0.5dBFS

-86.5

dBc

fIN = 3MHz at -0.5dBFS

-96.8

fIN = 32.5MHz at -0.5dBFS

-95.1

Third Harmonic

HD3

fIN = 70MHz at -0.5dBFS

-85.1

dBc

Intermodulation Distortion

IMD

fIN1 = 68.5MHz at -7dBFS
fIN2 = 71.5MHz at -7dBFS

-81.1

dBc

Third-Order Intermodulation

IM3

fIN1 = 68.5MHz at -7dBFS
fIN2 = 71.5MHz at -7dBFS

-84.4

dBc

Two-Tone Spurious-Free
Dynamic Range

SFDRTT

fIN1 = 68.5MHz at -7dBFS
fIN2 = 71.5MHz at -7dBFS

85.4

dBc

Aperture Delay

tAD

Figure 4

0.9

ns

Aperture Jitter

tAJ

Figure 4

<0.2

psRMS

Output Noise

nOUT

INP = INN = COM

0.52

LSBRM

Overdrive Recovery Time

±10% beyond full scale

1

Clock

cycles

INTERNAL REFERENCE (REFIN = REFOUT; VREFP, VREFN, and VCOM are generated internally)

REFOUT Output Voltage

VREFOUT

1.978

2.048

2.079

V

COM Output Voltage

VCOM

VDD / 2

1.65

V

Differential Reference Output

VREF

VREF = VREFP - VREFN

1.024

V

REFOUT Load Regulation

35

mV/mA

REFOUT Temperature Coefficient

TCREF

+50

ppm/°C

Short to VDD—sinking

0.24

REFOUT Short-Circuit Current

Short to GND—sourcing

2.1

mA

BUFFERED EXTERNAL REFERENCE (REFIN driven externally; VREFIN = 2.048V, VREFP, VREFN, and VCOM are generated
internally)

REFIN Input Voltage

VREFIN

2.048

V

REFP Output Voltage

VREFP

(VDD/2) + (VREFIN / 4)

2.162

V
