Quad band gsm/gprs module wireless makes smarter

GPRS Multi-slot Class 12
Extended Temperature
Range -45 °C to +85 °C
Embedded Internet Services
Protocols
RoHS Compliant
Serial Port
Multiplexer (GSM0710)
Quectel Enhanced AT
Commands
Quad Band
The M16 is a complete Quad-band GSM/GPRS solution in a
ZIF connector type which can be embedded in customer
application, offering the highest reliability and robustness.
Featuring an industry-standard interface, the M16 delivers
GSM/GPRS 850/900/1800/1900MHz performance for voice,
SMS, data, and fax in a form factor with extremely low power
consumption. With a configuration of 54.5mm x 36mm x
4.5mm,
M16 can fit into almost all the M2M applications,
including VTS, Smart Metering, Wireless POS, Security, etc.
● Quad - band GSM/GPRS module with a size
of 54.5mmx36mmx4.5mm
● ZIF connector suits for customer application
● Embedded powerful Internet service protocols
● Based on mature and field-proven platform, backed up
by our support service, from definition to design and
production
M16
Quad Band GSM/GPRS Module
Wireless makes smarter
