MAX1213
1.8V, 12-Bit, 170Msps ADC for
Broadband Applications
_______________________________________________________________________________________
3
ELECTRICAL CHARACTERISTICS (continued)
(AV
CC
= OV
CC
= 1.8V, AGND = OGND = 0, f
SAMPLE
= 170MHz, differential sine-wave clock input drive, 0.1µF capacitor on REFIO,
internal reference, digital output pins differential R
L
= 100Ω ±1%, T
A
= T
MIN
to T
MAX
, unless otherwise noted. ≥+25°C guaranteed by
production test, <+25°C guaranteed by design and characterization. Typical values are at T
A
= +25°C.)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
CLOCK INPUTS (CLKP, CLKN)
Differential Clock Input Amplitude
(Note 2)
200
500
mV
P-P
Clock Input Common-Mode
Voltage Range
1.15 ±0.25
V
Clock Differential Input
Resistance
R
CLK
11
±25%
k
Ω
Clock Differential Input
Capacitance
C
CLK
5
pF
DYNAMIC CHARACTERISTICS (at -2dBFS)
f
IN
= 10MHz, T
A
= +25
°
C
64
65.5
f
IN
= 65MHz, T
A
= +25
°
C
64
65.2
f
IN
= 190MHz
64
Signal-to-Noise
Ratio
SNR
f
IN
= 250MHz
62.8
dB
f
IN
= 10MHz, T
A
= +25
°
C
64
65.4
f
IN
= 65MHz, T
A
= +25
°
C
63.5
64.9
f
IN
= 190MHz
62.9
Signal-to-Noise
and Distortion
SINAD
f
IN
= 250MHz
62.3
dB
f
IN
= 10MHz, T
A
= +25
°
C
77
85
f
IN
= 65MHz, T
A
= +25
°
C
73
78
f
IN
= 190MHz
69.7
Spurious-Free
Dynamic Range
SFDR
f
IN
= 250MHz
71.4
dBc
f
IN
= 10MHz, T
A
= +25
°
C
-85
-77
f
IN
= 65MHz, T
A
= +25
°
C
-78
-73
f
IN
= 190MHz
-69.7
Worst Harmonics
(HD2 or HD3)
f
IN
= 250MHz
-71.4
dBc
Two-Tone Intermodulation
Distortion
TTIMD
f
IN1
= 209MHz at -7dBFS,
f
IN2
= 210MHz at -7dBFS
-66.7
dBc
Noise Power Ratio
NPR
f
NOTCH
= 22MHz
±
1MHz,
noise BW = 35MHz, A
IN
= -9.1dBFS
62.2
dB
LVDS DIGITAL OUTPUTS (D0P/N–D11P/N, ORP/N)
Differential Output Voltage
|V
OD
|
R
L
= 100
Ω
±
1%
250
400
mV
Output Offset Voltage
OV
OS
R
L
= 100
Ω
±
1%
1.125
1.310
V
