Rainbow Electronics M33 User Manual
Quad band gsm/gprs module wireless makes smarter

The M33 is a complete Quad-band GSM/GPRS module with 8-bit
CCIR656, CMOS camera sensor interface which supports YUV422/
YUV411/ YUV420 data format and up to 300K pixels CMOS camera
input. It can be embedded in security device to implement photo taking,
JPEG compression and MMS transfer. Customer can easily develop the
whole security equipment through Quectel solution.
Featuring an industry-standard interface, the M33 delivers GSM/GPRS
850/900/1800/1900MHz performance for voice, SMS, data, and fax in a
form factor with extremely low power consumption. With a size
configuration of 40mm x 32.2mm x 6mm and four soldering pins, M33
can be fixed in host PCB easily. A 300k pixels CMOS camera or CCIR656
interface digital video can be connected to M33 directly. Customer
application implements the photo handling and transfer function through
AT commands.
●Quad-band GSM/GPRS module with a size of 40mmx32.2mmx6mm
●Support 300k pixels CMOS camera and CCIR656 digital video interface
●JPEG compression
●MMS protocol
●100-pin B2B connector to supply rich interface resource
●4 soldering pins for easy fixing in host PCB
●Embedded powerful Internet service protocols
●Based on mature and field-proven platform
M33
Quad Band GSM/GPRS Module
Wireless makes smarter
GPRS Multi-slot Class 12
Extended Temperature
Range -45 °C to +85 °C
Revolutionary Camera
Interface
Embedded TCP/IP and
HTTP Protocols
Embedded MMS, FTP
and SMTP Client
Quectel Enhanced AT
Commands
Quad Band
Serial Port
Multiplexer (GSM0710)
PCM
Optional with SIM
holder or SIM IC
Micro SD Card
