Page 2: Output current source characteristics
DS4432
Dual-Channel, I
2
C, 7-Bit Sink/Source
Current DAC
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
RECOMMENDED OPERATING CONDITIONS
(T
A
= -40°C to +85°C.)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Voltage Range on V
CC
, SDA, and SCL
Relative to Ground.............................................-0.5V to +6.0V
Voltage Range on FS0, FS1, OUT0, OUT1
Relative to Ground..................................-0.5V to (V
CC
+ 0.5V)
(Not to exceed 6.0V.)
Operating Temperature Range ...........................-40°C to +85°C
Storage Temperature Range .............................-55°C to +125°C
Soldering Temperature ...............................Refer to the IPC/JEDEC
J-STD-020 Specification.
PARAMETER SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Supply Voltage
V
CC
(Note
1)
2.7
5.5
V
Input Logic 1 (SDA, SCL)
V
IH
0.7
x
V
CC
V
CC
+ 0.3
V
Input Logic 0 (SDA, SCL)
V
IL
-0.3
0.3
x
V
CC
V
Full-Scale Resistor Values
R
FS0
, R
FS1
(Note
2)
40
160
k
DC ELECTRICAL CHARACTERISTICS
(V
CC
= +2.7V to +5.5V, T
A
= -40°C to +85°C.)
PARAMETER SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Supply Current
I
CC
V
CC
= 5.5V (Note 3)
150
μA
Input Leakage (SDA, SCL)
I
IL
V
CC
= 5.5V
1
μA
Output Leakage (SDA)
I
L
1 μA
V
OL
= 0.4V
3
Output Current Low (SDA)
I
OL
V
OL
= 0.6V
6
mA
RFS Voltage
V
RFS
0.997
V
I/O Capacitance
C
I/O
10
pF
OUTPUT CURRENT SOURCE CHARACTERISTICS
(V
CC
= +2.7V to +5.5V, TA = -40°C to +85°C.)
PARAMETER SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Output Voltage for Sinking Current V
OUT:SINK
(Note
4)
0.5
3.5
V
Output Voltage for Sourcing
Current
V
OUT:SOURCE
(Note
4)
0
V
CC
-
0.75
V
Full-Scale Sink Output Current
I
OUT:SINK
(Notes 1, 4)
50
200
μA
Full-Scale Source Output Current I
OUT:SOURCE
(Notes 1, 4)
-200
-50
μA
Output Current Full-Scale
Accuracy
I
OUT:FS
+25°C, V
CC
= 3.3V; using 0.1% R
FS
resistor, V
OUT0
= V
OUT1
= 1.2V (Note 2)
±5
%
Output Current Temperature
Coefficient
I
OUT:TC
(Note
5)
±130
ppm/°C
