DS1666
6 of 9 102899
ANALOG RESISTOR CHARACTERISTICS (-40
°C to +85°C; V
CC
= 5.0V ± 10%)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Total Resistance
“-10”
“-50”
“-100”
10
50
100
K
Ω
K
Ω
K
Ω
5
5
5
End-to-End Resistor Tolerance -20 +20 % 8
Absolute Tolerance
Low End (0.25% Increments)
High End (1.5% Increments)
-0.5
-2.0
+0.5
+2.0
%
%
6
6
-3 dB Cutoff Frequency f
CUTOFF
MHz 7
Temperature Coefficient 750 ppm/
°C
AC ELECTRICAL CHARACTERISTICS (-40
°C to +85°C; V
CC
= 5.0V ± 10%)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
CS to INC Setup
t
CI
100 ns
INC High to U/ D Change
t
ID
100 ns
U/ D to INC Setup
t
DI
1 µs
INC Low Period
t
IL
500 ns
INC High Period
t
IH
1 µs
INC Low to Wiper Change
t
IW
200 ns
