DS1855
19 of 20
TYPICAL OPERATING CHARACTERISTICS (cont.)
(V
CC
= 5V, T = +25ºC, unless otherwise specified)
RESISTANCE vs. VOLTAGE (POWER-DOWN)
0
10,000
20,000
30,000
40,000
50,000
60,000
70,000
0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0
SUPPLY VOLTAGE - POWER-DOWN (V)
Pot 0 (50dec)
Pot 1 (127dec)
Pot 0 (0dec)
Pot 1 (0dec)
Pot 0 (99dec)
Pot 1 (255dec)
Pot 1 set to 127 decimal
Pot 0 set to 50 decimal
Pot 1 set to 0 decimal
Pot 1 set to 255 decimal
Pot 0 set to 99 decimal
Pot 0 set to 0 decimal
RE
S
IS
T
ANCE
FROM W TO L
(W
)
