DS1855
17 of 20
TYPICAL OPERATING CHARACTERISTICS (cont.)
(V
CC
= 5V, T = +25ºC, unless otherwise specified)
ATTE
NUATION (dB)
E
ND-TO-E
ND RE
S
IS
T
ANCE
CHANGE
(%)
ATTENUATION vs. FREQUENCY
-20
-15
-10
-5
0
10 100 1,000 10,000 100,000 1,000,000 10,000,000
FREQUENCY (Hz)
Pot 0, 10KOhms
Pot 1, 50kOhms
END-TO-END RES % CHANGE vs. TEMPERATURE
-2.0%
-1.5%
-1.0%
-0.5%
0.0%
0.5%
1.0%
1.5%
2.0%
2.5%
-40 -20 0 20 40 60 80
TEMPERATURE (C)
Pot 0 (10K)
Pot 1 (50K)
