Integrated Circuits Inc.
aP89341/170/085
Ver 2.1 14 Aug 24, 2006
DC CHARACTERISTICS
( T
A
= 0 to 70℃, V
DD
= 3.3V, V
SS
= 0V )
Symbol Parameter
Min.
Typ.
Max.
Unit
Condition
VDD
Operating Voltage
2.2
3.0
3.6
V
ISB
Standby current
1
5
μA
I/O open
IOP
Operating current
15
mA
I/O open
VIH
"H" Input Voltage
2.5
3.0
3.5
V
VDD=3.0V
VIL
"L" Input Voltage
-0.3
0
0.5
V
VDD=3.0V
IOL
V
OUT
low O/P Current
120
mA
Vout=0.3V
IOH
V
OUT
high O/P Current
-65
mA
Vout=2.5V
ICO
C
OUT
O/P Current
-3
mA
VCOUT=1.0V
IOH
O/P high Current
-8
mA
VOH=2.5V
IOL
O/P low Current
8
mA
VOL=0.3V
∆
F/F
Frequency Stability
-5
+5
%
Fosc(3V)
Fosc(3.4V)
-
Fosc(2.7V)
