Integrated Circuits Inc. aP89341/170/085
Ver 2.1 13 Aug 24, 2006
BLOCK DIAGRAM
Fig. 17 Block Diagram
ABSOLUTE MAXIMUM RATINGS
Symbol Rating Unit
V
DD
- V
SS
-0.5 ~ +3.8 V
V
IN
V
SS
- 0.3
IN DD
+ 0.3 V
V
OUT
V
SS OUT DD
V
T (Operating):
DIP
SOP
-10 ~ +70
-40 ~ +85
℃
T (Junction) -40 ~ +125 ℃
T (Storage) -55 ~ +125 ℃
