AT90S/LS2323/2343
1004D–09/01
Electrical Characteristics
Notes:
1. “Max” means the highest value where the pin is guaranteed to be read as low.
2. “Min” means the lowest value where the pin is guaranteed to be read as high.
3. Minimum V
CC
for Power-down is 2V.
Absolute Maximum Ratings*
Operating Temperature.................................. -55
°C to +125°C
*NOTICE:
Stresses beyond those listed under “Absolute
Maximum Ratings” may cause permanent dam-
age to the device. This is a stress rating only and
functional operation of the device at these or
other conditions beyond those indicated in the
operational sections of this specification is not
implied. Exposure to absolute maximum rating
conditions for extended periods may affect
device reliability.
Storage Temperature ..................................... -65
°C to +150°C
Voltage on Any Pin except RESET
with respect to Ground ..............................-1.0V to V
CC
+ 0.5V
Voltage on RESET with Respect to Ground ....-1.0V to +13.0V
Maximum Operating Voltage ............................................ 6.6V
DC Current per I/O Pin ............................................... 40.0 mA
DC Current
V
CC
and GND Pins................................ 200.0 mA
DC Characteristics
T
A
= -40
°C to 85°C, V
CC
= 2.7V to 6.0V (unless otherwise noted)
Symbol
Parameter
Condition
Min
Typ
Max
Units
V
IL
Input Low Voltage
(Except XTAL)
-0.5
0.3 V
V
V
IL1
Input Low Voltage
XTAL
-0.5
0.1
V
V
IH
Input High Voltage
(Except XTAL, RESET)
0.6 V
V
CC
+ 0.5
V
V
IH1
Input High Voltage
XTAL
0.7 V
V
CC
+ 0.5
V
V
IH2
Input High Voltage
RESET
0.85 V
CC
V
CC
+ 0.5
V
V
OL
Output Low Voltage Ports B
I
OL
= 20 mA, V
CC
= 5V
I
OL
= 10 mA, V
CC
= 3V
0.5
0.4
V
V
V
OH
Output High Voltage Ports B
I
OH
= -3 mA, V
CC
= 5V
I
OH
= -1.5 mA, V
CC
= 3V
4.2
2.4
V
V
I
IL
Input Leakage
Current I/O Pin
V
CC
= 6V, Pin Low
(absolute value)
8.0
µ
A
I
IH
Input Leakage
Current I/O Pin
V
CC
= 6V, Pin High
(absolute value)
8.0
µ
A
RRST
Reset Pull-up
100.0
500.0
k
Ω
R
I/O
I/O Pin Pull-up
30.0
150.0
k
Ω
I
CC
Power Supply Current
AT90S2343
Active 4 MHz, V
CC
= 3V
3.0
mA
Idle 4 MHz, V
CC
= 3V
1.1
mA
Power-down 4 MHz
V
CC
= 3V WDT Enabled
25.0
µ
A
Power-down 4 MHz
V
CC
= 3V WDT Disabled
20.0
µ
A
Power Supply Current
AT90S2323
Active 4 MHz, V
CC
= 3V
4.0
mA
Idle 4 MHz, V
CC
= 3V
1.0
1.2
mA
Power-down
,
V
CC
= 3V WDT Enabled
9.0
15.0
µ
A
Power-down
,
V
CC
= 3V WDT Disabled
<1.0
2.0
µ
A
