INTEGRATED CIRCUITS INC.
- APR9600
http://www.aplusinc.com.tw Page / 17 Ver2.1 13
VSSA 13
Analog GND Connection: Connect
system ground.
Same as Random
Access Mode.
Same as Random
Access Mode.
SP+ 14
Positive Output for Speaker
Connection: Should be connected to
the positive terminal of the output
speaker. Total output power is
12.2mW into 16 ohms. Do not use
speaker loads lower than 8 ohms or
device damage may result.
Same as Random
Access Mode. Same as Random
Access Mode.
SP- 15
Negative Output for Speaker
Connection: Should be connected to
the negative terminal of the output
speaker
Same as Random
Access Mode. Same as Random
Access Mode.
VCCA 16
Analog Positive Power Supply: This
connection supplies power for on-chip
analog circuitry. Should be connected
to the positive supply rail as out lined
in the reference schematics
Same as Random
Access Mode. Same as Random
Access Mode.
MicIn 17
Microphone Input: Should be
connected to the microphone input
as outlined in the reference
schematics.
Same as Random
Access Mode.
Same as Random
Access Mode.
MicRef 18
Microphone GND Reference:
Should be connected to the
microphone input as outlined in the
reference schematics.
Same as Random
Access Mode. Same as Random
Access Mode.
AGC 19
Automatic Gain Control Attack
Time: The time constant of the RC
network connected to this input
determines the AGC attack time.
The attack time is defined as the
delay present before the AGC
circuit begins to adjust gain. The
values shown in the reference
schematics have been optimized
for voice Applications.
Same as Random
Access Mode. Same as Random
Access Mode.
ANA_IN 20
Analog In: This pin must be
connected to ANA_OUT through a
0.luF Capacitor.
Same as Random
Access Mode. Same as Random
Access Mode.
ANA_OUT 21
Analog Out: This pin must be
connected to ANA_IN through a
0.luF Capacitor.
Same as Random
Access Mode. Same as Random
Access Mode.
STROBE 22
Strobe: This pin indicates
programming of each individual
recording segment. The falling
edge represents the beginning of
the sector. The rising edge
indicates that the sector is half full.
Same as Random
Access Mode.
Same as Random
Access Mode.
/CE 23
Chip Select: A low level on this pin
enables the device for operation.
Chip Select: A low level
on this pin enables the
device for operation.
Toggling this pin also
resets several
message management
features.
Chip Select: A low level
on this pin enables the
device for operation.
Toggling this pin also
resets several
message management
features.
MSEL1 24
Mode Select1: This pin in conjunction
with MSEL2 and /M8_OPTION sets
record and playback operating mode.
Consult table 1 for decoding
information.
Same as Random
Access Mode. Same as Random
Access Mode.
MSEL2 25
Mode Select2: This pin in conjunction
with MSEL1 and /M8_OPTION sets
cord and playback operating mode.
Consult table 1 for decoding information.
Same as Random
Access Mode. Same as Random
Access Mode.
