DS1371
2 of 14
ABSOLUTE MAXIMUM RATINGS
Voltage Range on V
CC
Pin Relative to Ground -0.3V to +6.0V
Voltage Range on SDA, SCL, and WDS Relative to Ground -0.3V to V
CC
+0.5V
Operating Temperature Range -40°C to +85°C
Storage Temperature Range -55°C to +125°C
Soldering Temperature See IPC/JEDEC J-STD-020A
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only,
and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is
not implied. Exposure to absolute maximum rating conditions for extended periods can affect device reliability.
RECOMMENDED DC OPERATING CONDITIONS
(T
A
= -40°C to +85°C)
PARAMETER SYMBOL MIN TYP MAX UNITS
Supply Voltage (Note 1) V
CC
1.7 3.3 5.5 V
Input Logic 1 (Notes 2, 3) V
IH
0.7 V
CC
V
CC
+ 0.3 V
Input Logic 0 (Notes 2, 3) V
IL
-0.3 0.3V
CC
V
DC ELECTRICAL CHARACTERISTICS
(V
CC
= 1.7V to 5.5V, T
A
= -40°C to +85°C, unless otherwise noted.) (Note 4)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Supply Voltage (Note 1) V
CC
1.7 5.5 V
Oscillator Operating Voltage
Range (Note 1)
V
OSC
1.3 5.5 V
Input Leakage I
LI
(Note 2) 1 mA
I/O Leakage I
LO
(Note 3) 1 mA
V
CC
> 2V; V
OL
= 0.4V
SDA Logic 0 Output (Note 1) I
OLSDA
V
CC
< 2V; V
OL
= 0.2V
CC
3 mA
V
CC
> 2V; V
OL
= 0.4V 3.0
1.7V < V
CC
< 2V;
V
OL
= 0.2V
CC
3.0
mA
SQW/INT Logic 0 Output
(Note 1)
I
OLSQW
1.3V < V
CC
< 1.7V;
V
OL
= 0.2V
CC
250 mA
Active Supply Current I
CCA
(Note 5) 100 150 mA
Timekeeping Current
(Oscillator Enabled, INTCN = 1)
I
OSC0
(Notes 6, 7) 800 nA
Timekeeping Current
(Oscillator Enabled, INTCN = 0)
I
OSC1
(Notes 6, 7) 1300 nA
Data Retention Current
(Oscillator Disabled)
I
DDR
(Note 6) 50 nA
