DS1805
Addressable Digital Potentiometer
2 _____________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
RECOMMENDED DC OPERATING CONDITIONS
(T
A
= -40°C to +85°C)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Voltage on Any Pin Relative to Ground .................-0.5V to +6.0V
Operating Temperature Range ...........................-40°C to +85°C Storage Temperature Range .............................-55°C to +125°C
Soldering Temperature............................................See IPC/JEDEC
J-STD-020A Specification
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Supply Voltage V CC
(Note 1) 2.7 5.5 V
Resistor Inputs L, H, W (Note 1) GND - V
CC
+ V
DC ELECTRICAL CHARACTERISTICS
(V CC = 2.7V to 5.5V, T A = -40°C to +85°C.)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Input Leakage I IL -1 +1 µA
Wiper Resistance R W 400 1000 Ω
Wiper Current I W 1 mA
Input Logic 1 V IH 0.7V CC
V CC +
0.3
V
Input Logic 0 V IL
GND -
0.3
0.3V CC V
Input logic 1 0.7V
CC
V CC +
0.3
Input Logic Levels A0, A1, A2
(Note 2)
Input logic 0
GND -
0.3
0 . 2 5 V C C
V
Input Current each I/O Pin
(Note 3)
0.4V < V I/O < 0.9V CC -10 +10 µA
Standby Current I STBY (Note 4) 20 40 µA
V
OL1
3mA sink current 0 0.4 V
Low-Level Output Voltage
V OL2 6mA sink current 0 0.6 V
I/O Capacitance C I/0 10 pF
Pulse Width of Spikes that Must
be Suppressed by the Input Filter
t SP Fast mode 0 50 ns
