ABSOLUTE MAXIMUM RATINGS*
Voltage on Any Pin Relative to Ground -0.3V to +7.0V
Operating Temperature 0° to 70°C
Storage Temperature -40°C to +70°C
Soldering Temperature 260°C for 10 seconds (See Note 7)
* This is a stress rating only and functional operation of the device at these or any other conditions above
those indicated in the operation sections of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods of time may affect reliability.
RECOMMENDED DC OPERATING CONDITIONS (0°C to 70°C)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Power Supply Voltage V
CC
4.5 5.0 5.5 V 1
Input Logic 1 V
IH
2.3 V
CC
+0.3 V 1
Input Logic 0 V
IL
-0.3 0.8 V 1
DC ELECTRICAL CHARACTERISTICS (0°C to 70°C; VCC = 5.0V ± 10%)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Average V
CC
Power Supply
Current
I
CC1
7 15 mA 2
Input Leakage I
IL
-1.0 +1.0 µ A 3
I/O Leakage I
OL
-1.0 +1.0 µ A 4
Input Current I
MOT
-1.0 +500 µ A 3
Output @ 2.4V I
OH
-1.0 mA 1,5
Output @ 0.4V I
OL
4.0 mA 1
Write Protect Voltage V
TP
4.0 4.25 4.5 V
CAPACITANCE (tA = 25°C)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Input Capacitance C
IN
5 pF
Output Capacitance C
OUT
7 pF
