INTEGRATED CIRCUITS INC.--
APC58120
www.aplusinc.com.tw Page / 18 VER1.0 6
11)0AH [7:0] Timer/Counter A Control register{RW}
[2:0] < TAPS2, TAPS1, TAPS0> Timer prescaler bit
TAPS2 TAPS1 TAPS0 rate
0 0 0 1:2
0 0 1 1:4
0 1 0 1:8
0 1 1
1:16
1 0 0 1:32
1 0 1 1:64
1 1 0 1:128
1 1 1 1:256
[4]
0:Timer A Prescaler Disable Prescale Rate 1:1
1:Timer A Prescaler Enable(default)
[5]
0: select system clock(default)
1: select crystal clock(32768)
[6]< TAEN> Timer/Counter Enable control
0: Timer/Counter disable(default)
1: Timer/Counter enable
[7] Timer/Counter Interrupt Enable control
0: Timer/Counter interrupt disable(default)
1: Timer/Counter interrupt enable
12)0BH [7:0] Timer/Counter B Control register{RW}
[2:0] < TBPS2, TBPS1, TBPS0> Timer prescaler bit
TBS2 TBS1 TBS0 rate
0 0 0 1:2
0 0 1 1:4
0 1 0 1:8
0 1 1
1:16
1 0 0 1:32
1 0 1 1:64
1 1 0 1:128
1 1 1 1:256
[4]
0:Timer B Prescaler Disable Prescale Rate 1:1
1:Timer BPrescaler Enable(default)
[5]
0: select system clock(default)
1: select crystal clock(32768)
[6]< TBEN> Timer/Couner Enable control
0: Timer/Counter disable(default)
1: Timer/Counter enable
[7] Timer/Counter Interrupt Enable control
0: Timer/Counter interrupt disable(default)
1: Timer/Counter interrupt enable
