INTEGRATED CIRCUITS INC.--
APC58120
www.aplusinc.com.tw Page / 18 VER1.0 2
3. Memory mapping :
Address Register
00h INDirect addressing register ( IND0 )
01h Memory Index Register (MIR0)
02h INDirect addressing register ( IND1 )
03h Memory Index Register (MIR1)
04h Program register(PC)
05h Status Flag Register ( SFR )
06h Timer_A
07h Timer_B
08h Timer_C
09h Timer_D
0Ah TCA register
0Bh TCB register
0Ch TCC register
0Dh TCD register
0Eh Port A data Register ( RPA )
0Fh Port A Control register CPA
10h Port B data Register ( RPB )
11h Port B Control register CPB
12h Watchdog Timer Control Register
13h Interrupt Flag Register(IFR)
14h PLL Control register
15h PortA Interrupt control register
16h PortA Pull High register
17h PortB Pull High register
18h PortA Pull Down register
19h PortB Pull Down register
1Ah PortA edge Control register
1Bh Table Pointer Register High Word
1Ch Table Pointer Register Low Word
1Dh Data Pointer Register High Word
1Eh Data Pointer Register Low Word
1Fh M1
20h M0
21h C1
22h C0
23h Other
register
24h PIR register
25h PLLSEL register
30H~3FFH RAM
