5.Function Control Registers:
Address Name
Bit15/
Bit7
Bit14/
Bit6
Bit13/
Bit5
Bit12/
Bit4
Bit11/
Bit3
Bit10/
Bit2
Bit9/
Bit1
Bit8/
Bit0
00h IND0[9:0]
Use contents of MIR0 to address data memory
(not a physical register)
01h MIR0[9:0] Indirect data memory address pointer 0
02h IND1[9:0]
Use contents of MIR1 to address data memory
(not a physical register)
03h MIR1[9:0] Indirect data memory address pointer 1
04h PC Program Counter register
05h SFR[7:0] Ponrst WT SP Z AC C
06h Timer_A 8 bits of real timer clock/counter
07h Timer_B 8 bits of real timer clock/counter
08h Timer_C 8 bits of real timer clock/counter
09h Timer_D Fix Timer
0Ah TCA[7:0] TAEI TAEN
TACK
SEL
TAPRE
EN
TAPS2 TAPS1 TAPS0
0Bh TCB[7:0] TBEI TBEN
TBCK
SEL
TBPRE
EN
TBPS2 TBPS1 TBPS0
0Ch TCC[7:0] TCEI TCEN
TCCK
SEL
TCPRE
EN
TCPS2 TCPS1 TCPS0
0Dh TCD[7:0] TDEI TDEN TDPS2 TDPS1 TDPS0
0Eh RPA[15:0] Port A data Register
0Fh CPA[15:0] Port A Control register
10h RPB[7:0] Port B data Register
11h CPB[7:0] Port B Control register
12h WTC[7:0]
WTPS
C2
WTPS
C1
WTPS
C0
13h IFR[7:0]
Timer_
DF
Timer_
CF
Timer_
BF
Timer_
AF
13h IFR[15:8]
PortA7
_F
PortA6
_F
PortA5
_F
PortA4
_F
PortA3
_F
PortA2
_F
PortA1
_F
PortA0
_F
14h PLLC[5:0]
PWME
N
DACE
N
PLLEN
PLLCl
ksel1
PLLCl
ksel0
15h IPA[7:0] PortA Interrupt control register
16h PHA PortA Pull High register
17h PHB PortB Pull High register
18h PDA PortA Pull Down register
19h PDB PortB Pull Down register
1Ah PADC PortA Edge Control register
1Bh TDPTRH[16] Table Pointer Register High Word
1Ch TDPTRL Table Pointer Register Low Word
1Dh DPTRH Data Pointer Register High Word
1Eh DPTRL Data Pointer Register Low Word
1Fh M1 Result of multiplier high word
20h M0 Result of multiplier Low word
21h C1 Channel 1 register
22h C0 Channel 0 register
