9. Instruction Set :
Binary Code Syntax Operation Status Affected
00000000
0000000000000000
NOP None None
00001111 11111110
000nnnnn
SHLM n
SLM M1M0 n bit→M1M0
sign →M1M0[31]
0 →M1M0[n-1:0]
None
00001111
11111111 000nnnnn
SHRM n
SRM M1M0 n bit→M1M0
sign →M1M0[31]
sign →M1M0[31:31-n]
None
00001111
11111110 001nnnnn
SHSLM n
SLM M1M0 n bit→M1M0
{SATURATION}
sign →M1M0[31]
0 →M1M0[n-1:0]
None
00001111 11111111
001nnnnn
SHSRM n
SRM M1M0 n bit→M1M0
{SATURATION}
sign →M1M0[31]
sign→M1M0[31:31-n]
None
00001111
11111111 11110110
CLRWT 0→WT
00001111
11111111 11110111
STDBY Stop Clock SP=0
00001111
11111111 11111000
SLEEP Stop OSC SP=0
00001111
11111111 11111001
RET Stack→PC None
00001111
11111111 11111010
RETI Stack→PC None
00001111 11111111
11111011
SKIPA PC+A →PC None
00001111 11111111
11110100
TLBDA (TDPTR[31:0])(Byte mode)→A Z
00001111 11111111
11110101
TLBPA
(TDPTR[31:0])(Byte mode)→A
tdptr+=1
Z
00001111 11111111
11111100
TLDDA (TDPTR[31:0])→A Z
00001111 11111111
11111101
TLDPA (TDPTR[31:0])→A,tdptr+=1 Z
00001111
11111111 11111110
LDDA (DPTR[31:0])→A Z
00001111
11111111 11111111
LDPA (DPTR[31:0])→A,dptr+=1 Z
00010000
iiiiiiii iiiiiiii
MULIA i i*A→M1M0 None
00010001
rrrrrrrr rrrrrrrr
MULAR r r*A →M1M0 None
