NOTES:
1. All voltages are referenced to ground.
2. Logic 1 voltages are specified at a source current of 1 mA.
3. Logic 0 voltages are specified at a sink current of 4 mA.
4. I
CC
specified with DQ pin open and CLK pin at V
DD
.
5. I
CC
specified with V
CC
at 5.0V and RST =GND.
6. Measured at V
IH
= 2.0V or V
IL
= 0.8V.
7. Measured at V
OH
= 2.4V or V
OL
= 0.4V.
8. Load capacitance = 50 pF.
9. t
CWH
must be 10 ms minimum following any write command that involves the E
2
memory.
10. See typical curve for specification limits outside 0
°
C to 70
°
C range.
11. Thermometer error reflects temperature accuracy as tested during calibration.
12. Writing to the nonvolatile memory should only take place in the 0
°
C to 70
°
C temperature range.
13. Valid for design revisions D1 and above. The supply range for Rev. C2 and below is 4.5V < 5.5V.
