10.1 GPIO Logic levels
Where not specifically stated, all the interface circuits work at 2.8V CMOS logic levels.
The following table shows the logic level specifications used in the
GM862-QUAD/PY interface circuits:
Absolute Maximum Ratings -Not Functional
Parameter Min Max
Input level on any digital
pin when on -0.3V +3.6V
Input voltage on analog
pins when on -0.3V +3.0 V
Operating Range - Interface levels (2.8V CMOS)
Level Min Max
Input high level 2.1V 3.3V
Input low level 0V 0.5V
Output high level 2.2V 3.0V
Output low level 0V 0.35V
For 2,0V signals:
Operating Range - Interface levels (2.0V CMOS)
Level Min Max
Input high level 1.6V 3.3V
Input low level 0V 0.4V
Output high level 1,65V 2.2V
Output low level 0V 0.35V
