ISD2100 DATASHEET
Publication Release Feb 9, 2010
- 14 - Revision 0.51
SYMBOL DESCRIPTION MIN TYP MAX UNIT
T
FALL
Fall Time for All Digital Signals --- --- 10 ns
T
SSBS
SSB Falling Edge to 1
st
SCLK Falling Edge Setup
Time
30 --- --- ns
T
SSBH
Last SCLK Rising Edge to SSB Rising Edge Hold
Time 30ns --- 50us ---
T
SSBHI
SSB High Time between SSB Lows 20 --- --- ns
T
MOS
MOSI to SCLK Rising Edge Setup Time 15 --- --- ns
T
MOH
SCLK Rising Edge to MOSI Hold Time 15 --- --- ns
T
ZMID
Delay Time from SSB Falling Edge to MISO Active -- -- 12 ns
T
MIZD
Delay Time from SSB Rising Edge to MISO Tri-state -- -- 12 ns
T
MID
Delay Time from SCLK Falling Edge to MISO --- --- 12 ns
T
CRBD
Delay Time from SCLK Rising Edge to RDY/BSYB
Falling Edge -- -- 12 ns
T
RBCD
Delay Time from RDY/BSYB Rising Edge to SCLK
Falling Edge 0 -- -- ns
