5.5 $GPGSA
GSA---GNSS DOP and Active Satellites
Table 5 contains the values for the following example:
$GPGSA,A,3,07,02,26,27,09,04,15, , , , , ,1.8,1.0,1.5*33
Table 5 GSA Data Format
Name
Example
Units
Description
Message ID
$GPGSA
GSA protocol header
Mode 1
A
See Table 7
Mode 2
3
See Table 6
Satellite Used in
solution
07
Sv on Channel 1
Satellite Used in
solution
02
Sv on Channel 2
Satellite Used
Sv on Channel 12
PDOP
1.8
Position Dilution of Precision
HDOP
1.0
Horizontal Dilution of Precision
VDOP
1.5
Vertical Dilution of Precision
Checksum *33
End of message termination
Table 6 Mode 2
Value
Description
1
Fix not available
2 2D
3 3D
Table 7 Mode 1
Value
Description
M
Manual- forced to operate in 2D or 3D mode
A
Automatic-allowed to automatically switch 2D/3D
