DS1867
11 of 14 102199
ANALOG RESISTOR CHARACTERISTICS (-40
°C to +85°C;V
CC
= 5V ± 10%)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
End-to-End Resistor Tolerance -20 +20 % 17
Absolute Linearity ±0.75
LSB
4
Relative Linearity ±0.30
LSB
5
-3 dB Cutoff Frequency f
CUTOFF
Hz 7
Noise Figure 120 dB/(Hz)1/2
Temperature Coefficient 750 ppm/ °C
CAPACITANCE (T
A
= 25
°C)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Input Capacitance C
IN
5 pF 3
Output Capacitance C
OUT
7 pF 3
AC ELECTRICAL CHARACTERISTICS (-40
°C to +85°C; V
CC
= 5V ± 10%)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
CLK Frequency f
CLK
DC 10 MHz 15
Width of CLK Pulse t
CH
50 ns 15
Data Setup Time t
DC
30 ns 15
Data Hold Time t
CDH
10 ns 15
Propagation Delay Time
Low to High Level
Clock to Output t
PLH
70 ns 13,15
Propagation Delay Time
High to Low Level
Clock to Output
t
PHL
70 ns 13,15
RST High to Clock Input High
t
CC
50 ns 15
RST Low to Clock Input High
t
HLT
50 ns 15
CLK Rise Time t
CR
50 ns 15
RST Inactive
t
RLT
200 ns 15
NONVOLATILE MEMORY CHARACTERISTICS
(-40
°C to +85°C; V
CC
= 5V ± 10%)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Writes 25000 16
