2
Standard ICs BA4510F / BA4510FV
•
Internal circuit configuration
V CC
V EE
R 2
R 3
A
R 1
Q 7
Q 1 – IN
+ IN
Q 2
OUT
R 4
X 3
X 2
Q 8
R 5
Q 9
•
Absolute maximum ratings (Ta = 25°C)
Parameter Symbol Limits Unit
Power supply voltage V
CC
±
5 V
Power dissipation
BA4510F
BA4510FV
550
∗
1 (SOP)
350
∗
2 (SSOP)
mW
Differential input voltage V
ID
±
V
CC
V
Common-mode input voltage V
I
0 ~ V
CC
V
Operating temperature Topr
°
C
Storage temperature Tstg
°
C
Pd
– 20 ~ + 75
– 40 ~ + 125
∗
1 If used at temperatures higher than 25
°
C, reduce power by 5.5mW for each 1
°
C above Ta = 25
°
C.
This value is the value measured when mounted on a glass epoxy board (50mm
×
50mm
×
1.6mm).
∗
2 If used at temperatures higher than 25
°
C, reduce power by 3.5mW for each 1
°
C above Ta = 25
°
C.
This value is the value measured when mounted on a glass epoxy board (70mm
×
70mm
×
1.6mm).
The value is 300mW when the IC is used alone.
