31
4979D–GPS–06/08
ATR0635P1
6.26
Input pull-up resistor
NRESET
A7 R
PU
0.5 1.8 k
Ω
A
6.27
Input pull-up resistors TCK,
TDI, TMS G9, H10,
G10
R
PU
7 18 k
Ω
A
6.28
Input pull-up resistors P9,
P13, P22, P31 A11, B10,
C10, D10
R
PU
100 235 k
Ω
A
6.29
Input pull-down resistors
DBG_EN, NTRST
E8, H11 R
PD
7 18 k
Ω
A
6.30
Input pull-down resistors
P0, P15, P30 C8, F11,
G12
R
PD
100 235 k
Ω
A
6.31
Configurable input pull-up
resistors P1, P2, P8, P12,
P14, P16 to P21, P23 to
P27, P29
VDDIO = 3.6V
V
PAD
= 0V
R
CPU
50 160 k
Ω
A
6.32
Configurable input
pull-down resistors P1, P2,
P8, P12, P14, P16 to P21,
P23 to P27, P29
VDDIO = 3.6V
V
PAD
= 3.6V
R
CPD
40 160 k
Ω
A
6.33
Configurable input pull-up
resistor USB_DP (idle state)
C9 R
CPU
0.9 1.575 k
Ω
A
6.34
Configurable input pull-up
resistor USP_DP (operation
state)
C9 R
CPU
1.425 3.09 k
Ω
A
6.35
Input pull-down resistors
USB_DP, USB_DM
C9, D9 R
PD
10 500 k
Ω
A
10. Electrical Characteristics (Continued)
If no additional information is given in column Test Conditions, the values apply to temperature range from –40°C to +85°C.
No. Parameters Test Conditions Pin Symbol Min Typ Max Unit Type*
*) Type means: A = 100% tested, B = 100% correlation tested, C = Characterized on samples, D = Design parameter
Notes: 1. The LDO18 is a built in low dropout voltage regulator, which can be used if the host system does not provide the core volt-
age VDD18.
2. The LDOBAT is a built in low dropout voltage regulator, which provides the supply voltage VBAT18 for the RTC, backup
SRAM, P9, P13, P22, P31, NSLEEP and NSHDN. The LDOBAT voltage regulator switches in battery mode if LDOBAT_IN
falls below 1.5V.
3. Supply voltage VBAT18 for backup domain is generated internally by the LDOBAT.
4. If no current is caused by outputs (pad output current as well as current across internal pull-up resistors)
