200mA, Automotive, Ultra-Low
Quiescent Current, Linear Regulator
MAX16910
2 ______________________________________________________________________________________
Typical Operating Circuits (continued)
MAX16910
IN
+
-
1µF
OUT
SETOV
RESET
ENABLE
1nF
(1.25ms DELAY)
4.7µF
V
CC
RESET
I/O
3.3V FIXED OUTPUT
TIMEOUT
SET
GND
14V
BATTERY
µC
10kI
MAX16910
IN
+
-
1µF
OUT
SETOV
RESET
SET
1nF
(1.25ms DELAY)
4.7µF
V
CC
RESET
I/O
ADJUSTABLE OUTPUT
TIMEOUT
GND
ENABLE
14V
BATTERY
µC
10kI
R2
R1
